Siglent SDS1072CNL 70MHz 2 Channel

SKU: Siglent SDS1072CNL

SDS1072CNL 70MHz 2 Channel


Features and Benefits:

● Up to 200MHz Bandwidth 1GSa/s sample rate
● 7''TFT-LCD display, 8*18 grids
● Channels: 2CH+1EXT
● Memory Depth: 40Kpts, 5Kpts/CH (SDS1202CNL)
● 6 digits hardware frequency counter, real time counting display
● Support SCPI programming command control
● Interface: USB Device, USB Host, RS-232, Pass/Fail
● Unique digital filter and data recorder function
● Embedded 12 languages, online help, one key storing and one key printing

Specification

Model

SDS1072CNL

Bandwidth

70MHz

Channels

2CH+1EXT

Real time sampling rate

70MHz

Channels

2CH+1EXT

Real time sampling rate

1GSa/s

Equivalent sampling rate

50GSa/s

Memory depth

40kpts

Rise time

< 5

Input impedance

1MΏ‖17pF

Time base range

Scan: 100ms-50s/div

Vertical sensitivity

2mV-10V/diov

Vertical resolution

8bit

Trigger source

CH1, CH2, Ext/5, AC Line

Trigger types

Edge, Pulse, Video, Slope, Alternative

Math Operation

+, -, x, ÷, FFT

Digital filter

High pass, Low pass, Band pass, Band stop

Max input voltage

±400V (DC+AC Pk-Pk), CAT I, CAT II

Internal storage

2 groups of reference waveform, 20 groups of settings, 10 groups of waveforms

External Storage

2 groups of reference waveform, 20 groups of settings, 10 groups of waveforms

External storage

Bitmap save, CSV save, Waveform save, Setting save

Language

English, French, German, Russian, Spanish, Simplified Chinese, Traditional Chinese, Portuguese, Japanese, Korean, Italian, Arabic

Interface

USB Host, USB Device, RS-232, Pass/Fall out

Display

7 inches (178mm) colour TFT (480*234) LCD

Power

AC 100-240V, 45Hz-440Hz, 50 VA Max

PC software

Can through the computer remote control oscilloscope, extraction waveform analysis data

Remark

With original source seamless connection, form signal collection, produce integration system
